LX-17
Large-format Luxform system, ideal for automotive bumpers and components, molds, and one-piece display and stage props.
Print volume1700 × 800 × 650 mm
Layer thickness0.05–0.2 mm
Scanning speed15 m/s
Machine weight2780 kg
Key features
Discover the LX-17
01
Intelligent high-speed scanning
Scanning system up to 15 m/s.
02
Variable laser spot and power
Spot from 0.08 to 0.8 mm, adapted to contours and infill.
03
Automatic upskin / downskin recognition
Dedicated parameter database for every layer thickness.
04
Full marble structure
Maximum stability for long-term printing accuracy.
05
High-rigidity recoater
Accuracy and efficiency on every layer.
06
Open resin platform
No proprietary cartridges: compatible with qualified third-party photopolymer resins.
Applications
Parts & realizations
Technical data
LX-17 — specifications
| Technology | Vat Photopolymerization (VP) |
|---|---|
| Print volume | 1700 × 800 × 650 mm |
| Machine footprint | 248 × 169 × 232 cm |
| Machine weight | 2780 kg |
| Installed power | 2.2 kVA |
| Laser source | Nd:YVO4 355 nm, variable spot 0.08–0.8 mm |
| Scanning speed | 15 m/s |
| Layer thickness | 0.05–0.2 mm |
| Accuracy | ±0.15 mm (L ≤ 100 mm) · ±0.15% × L (L > 100 mm) |
| Materials | Photopolymer resins (open system) |
