Machines / Granuflow / GF-8
Granuflow · PAM
GF-8
Compact pellet extruder for models, sculptures and small batches.
Print volume800 × 600 × 800 mm
Nozzle diameter0.4–2 mm
Power supply220 V · 1-phase
Machine weight~200 kg
Key features
Discover the GF-8
01
Automatic, continuous feeding
Pneumatic system with alarm when material runs out.
02
Emergency stop
Dedicated safety mode for the operator.
03
Precision hybrid structure
Belt-driven Z-axis and precision X/Y modules for stable printing.
04
Nozzle up to 350 °C
450 °C optional; fully enclosed sheet-metal cover for thermal insulation.
05
Ready to use
Fully integrated hoisting: plug in and start printing right away.
Applications
Parts & realizations
Technical data
GF-8 — specifications
| Technology | Pellet Additive Manufacturing (PAM / FGF) |
|---|---|
| Print volume | 800 × 600 × 800 mm |
| Machine footprint | 1500 × 1120 × 1740 mm |
| Nozzle diameter | 0.4–2 mm |
| Machine weight | ~200 kg |
| Max. nozzle temperature | 350 °C (450 °C optional) |
| Power supply | Single-phase 220 V |
| Materials | ABS, PETG, PLA, ASA, TPU, PC, PA, PP, (+GF/CF) |
Discuss your GF-8 application
Request a quote, a printed sample or technical information for your project.
